Main characteristics
Printing;Printing method: Direct thermal printing
;Resolution: 180 dpi
;Print speed: 220 mm/s
;Print width: 80 mm
Interfaces;Standard: USB (B type), Serial (RS-232C 25pin)
;Additional: Wi-Fi (802.11a/b/g/n), Bluetooth Smart Ready (Bluetooth4.2+BLE)
Paper output;Up
Bar codes;1D: Code 11, Code 39, Code 93, Codabar, ISBT-128, UPC-A, UPC-A, UPC-E,EAN-13, Code 128 with A/B/C,
;2D bar codes: PDF417, QR codes
Sensors;Paper end sensor, Cover open sensor
Power;AC 100V ~ 240V, 50/60Hz
;DC 24Vdc / 1.75A
Paper;Paper type: Thermal receipt paper
;Paper width: Max. 80mm
;Paper thickness: 0.05 ~ 0.09mm
;Paper roll diameter: Max. Ø 83mm
;Inner diameter of the roll core: 12.5mm ± 0.5mm
Environment;Operating conditions: 0°C ~ 45°C, 35% ~ 80%, non-condensing
;Storage conditions: -20°C ~ 60°C, 10% ~ 90%, non-condensing
Dimensions (W*D*H), mm; 130*140*154
Weight, kg;1.25
Software;Drivers: Windows, Linux, OPOS, JavaPOS, Mac, Android Plugin
;SDK: Windows, Android, iOS, Linux
